Loa 12’ – 6” (3.81m)
Beam 2’ – 9” (0.84m)
Weight (apprx.) 45lbs (20kgs)
Max. Load (apprx.) 400lbs (181kgs)
Height at Bow/Stern 19"/19" (0.48m/0.48m)
Height amidships 12" (0.30m)
Crew 1 plus 1
Basic Materials
3 x 6mm x 2.44m x 1.22m,
3kg Epoxy pack,
1.5ltr Fillet Additive,
30m x 100mm wide F/G Tape,
100 4.8mm x 300mm Cable Ties.
All the sizes have the same lines just different lengths and widths along with the ability to carry more the larger they get. Their performance has proved to be better than I expected, they track well even in a breeze with choppier conditions and are quite stable. All were designed to be paddled while kneeling but, as is far more popular these days, seats are an option and the plans do detail them. There are bulkheads fore and aft which, along with the decks, form a watertight compartment or buoyancy tanks. These can be fitted with small hatches for storage of valuables etc and to air the compartments when not in use. Alternatively, drain plugs or a simple hole drilled through the base with a cork or rubber bung to stop the water getting in could be used. In any case, some form of drainage should be fitted to them.
Available Options
Plans Packages –
Digital Download Plans - From the download option page
A3 Printed Workshop Plans - A3 drawings with full instruction manual
Full Size Paper Patterns Plans - Full size paper patterns of the main hull components with full instruction manual
top of page
SKU: PM12A3
£25.00 Regular Price
£22.50Sale Price
